FF300
Characteristics
It combines various melting techniques: on the wide dry sole you can melt heavier charges; from the chimney (charging hopper) the lighter charges, such as feedheads with specific loader (optional).| Furnace capacity | 1200 Kg molten aluminium |
| Melting capacity | 300 Kg / h. |
| Bath max temperature | 800 °C |
| Refractory max temperature | 1000 °C |
| Combustible gas | Natural gas |
| Number of burners | 1 |
| Max rating | 220.000 KCal/h |
| Installed power management | From 0 to 100% with limit of maximum |
| Power supply | Three-phase, 380 V/50 Hz |
| Auxiliary services | 24 V C.C./A.C. (Left out starting trasformers and UV probes, working at 220 V A.C.) |
| Continued and automatic control of molten aluminium temperature, by thermoregulator with thermocouple in the bath | |
| Thermo-limit of refractory temperature by thermoregulator not visualized and thermocouple in the wall | |
| Capacità | --DEMO-- |
| Temperatura max | --DEMO-- |
